| Board Name | Thumbnails | Dimensions | OSH Park Cost | OSH Stencils Estimate | |
|---|---|---|---|---|---|
| Top | Bottom | ||||
| 1. MicroUSB Power Board |
|
|
8.8 × 10.3 mm |
$0.70 for 3 $0.23 each |
$7.34 |
| 8. Kitchen LED Strip Temporary Off Button |
|
|
55 × 33.4 mm |
$14.22 for 3 $4.74 each |
$17.94 |
| 9. DHT-22 Proxy Board |
|
|
15.3 × 7.7 mm |
$0.91 for 3 $0.30 each |
$7.79 |
| 11b. ESP8266 proxy SIMPLE |
|
|
24.1 × 52.9 mm |
$9.88 for 3 $3.29 each |
$15.65 |
| 12. PICAXE Serial In Pull-Down Board |
|
|
16.3 × 6.6 mm |
$0.83 for 3 $0.28 each |
$7.75 |
| 13. PICAXE Programming Board |
|
|
16.3 × 11.2 mm |
$1.41 for 3 $0.47 each |
$8.37 |
| 15. Car DRL PICAXE Controller |
|
|
78.8 × 34.6 mm |
$21.16 for 3 $7.05 each |
$22.32 |
| 16. I2C ADC Board |
|
|
21.6 × 13 mm |
$2.16 for 3 $0.72 each |
$9.29 |
| 20. RPi GPIO Multiplier |
|
|
53.8 × 17.8 mm |
$7.42 for 3 $2.47 each |
$14.46 |
| 20. RPi GPIO Multiplier - Rotated |
|
|
60.9 × 21.9 mm |
$10.34 for 3 $3.45 each |
$16.36 |
| 20. RPi GPIO Multiplier - pHAT |
|
|
65.2 × 44.1 mm |
$22.30 for 3 $7.43 each |
$22.19 |
| 23. Washing Machine Notifier |
|
|
28.6 × 54.3 mm |
$12.05 for 3 $4.02 each |
$16.82 |
| 27. Neon Lamp 60-LED-Bulb-Housing |
|
|
43.7 × 43.7 mm |
$14.80 for 3 $4.93 each |
$17.99 |
| 28. Neopixel Jewel |
|
|
30.9 × 30.7 mm |
$7.37 for 3 $2.46 each |
$13.43 |
| 29. ESP8266 6x2mm to 6x2.54mm+Btns UART adapter |
|
|
24.4 × 17.8 mm |
$3.36 for 3 $1.12 each |
$10.39 |
| 30. D-Link Switch Fan Controller |
|
|
32.7 × 19.2 mm |
$4.86 for 3 $1.62 each |
$11.78 |
| 31. Tesco Dash |
|
|
42.7 × 25.9 mm |
$8.56 for 3 $2.85 each |
$14.44 |
